4000lbs Winch Synthetic Rope by VRS
R 3,995.00
Tax included. Shipping policy
Heavy duty sealed high amperage contactor
Pendant control
Textured UV and corrosion resistant finish
Sealed to resist water penetration
Mechanical braking system
Designed in Australia for the World
SPECIFICATIONS
...
- Free delivery on orders over R3 000
- Easy returns, based on the vendor's terms
- Secure payments: Visa, Mastercard, Amex, Zapper, SnapScan
Description
- Heavy duty sealed high amperage contactor
- Pendant control
- Textured UV and corrosion resistant finish
- Sealed to resist water penetration
- Mechanical braking system
- Designed in Australia for the World
SPECIFICATIONS
| Line Pull | 4,000lb/ 1,818kgs |
| Motor 12V | Permanent magnet 1.6hp/1.2kw DC12V |
| Gear Train | 3 stage planetary gears |
| Gear Ratio | 198: 1 |
| Freespool | Sliding ring gear |
| Brake | Automatic, in the drum |
| Battery | Recommended 650 CCA minimum for winching |
| Synthetic Rope Size | 6mm x 10m |
| Drum Size | 50mm x 76.5mm |
| Mounting Bolt Pattern | 124mm x 76mm |
| Dimensions | 334mm x 114mm x 120mm |
| Net Weight | 8.6kgs (19lbs) |
LINE PULL AND ROPE CAPACITY
| Layer of wire rope | Line Pull kg / lb | Total Rope on the Drum m/ft |
|---|---|---|
| 1st Layer | 1,818 / 4,000 | 2 / 6.6 |
| 2nd Layer | 1,460 / 3,225 | 4.3 / 14.1 |
| 3rd Layer | 1,225 / 2,700 | 7.2 / 23.6 |
| 4th Layer | 1,055 / 2,325 | 10 / 39 |
LINE SPEED AND AMP. DRAW*
| Line Pull kg/lb | Line Speed mpm/fpm | Amp. Draw 12V |
| No Load | 4.9 / 16.0 | 17 |
| 454 / 1,000 | 3.2 / 10.5 | 70 |
| 907 / 2,000 | 2.8 / 9.2 | 105 |
| 1,360 / 3,000 | 2.2 / 7.2 | 135 |
| 1,818 / 4,000 | 1.5 / 4.9 | 180 |
* 1ST LAYER OF ROPE ON THE DRUM
STANDARD ACCESSORIES
- Detachable Contactor Pack
- Remote pendant control
- Synthetic Rope with Hook
- Hawse fairlead
- Handsaver strap
Shipping & returns
Free delivery on orders over R3 000. Returns are handled per the brand’s terms and conditions.
SKU: T4000S
